Basic features：
1、high frequency27.12MHz, in line with international standards
2、automatic overcurrent protection devices
3、5557 anti-sensitive ignization device
4、high-frequency electromagnetic radiation safety standards
5、the appearance of beautifully designed , ergonomic fit
6、servo motor starting, accurate location
7、PLC human-machine interface,more convenient operation
8、infra-red sensing system ，Abnormal auto stop work
9、Stainless steel safety shield
Main application:
Pure PVC, EVA medical bag film automatic welding edge
Scope of Application:
Eg: The drainage bag, urine bag, infusion bag, medicine bag, urethral catheterization bag, blood bag
Machine parameters:
|
MODEL |
KS-8000MF |
KS-10000MF |
|
output power |
8KW |
10KW |
|
power input |
13KVA |
16KVA |
|
power voltage |
380V |
|
|
oscillation |
27.12MHz |
|
|
rectifier |
Silicon diode |
|
|
way of pressure |
Air pressure |
|
|
distance of machine moving |
150mm |
|
|
way of cooling |
Air cooling |
|
|
Electron tube |
7T69RB |
E3069RB |
|
size of Lower press plate |
550*600mm |
|
|
size of Upper edge pressure |
450*500mm |
|
|
size of machine |
4500*1500*1700mm |
|
|
Weight of machine |
900KG |
950KG |
|
Trademark of machine |
美之电 |
|
|
Remarks:Due to technological upgrading, parameters without further notice, please forgive |
||
